High Speed 0.4m/s Insulated Sectional Overhead Door 42mm PU Sandwich Panel R-Value 13.73 Energy Efficient
Datos del producto:
| Lugar de origen: | Porcelana |
| Nombre de la marca: | DESEO |
| Certificación: | CE/ISO9001:2008 |
| Número de modelo: | SD6100 |
Pago y Envío Términos:
| Cantidad de orden mínima: | 1 unidad |
|---|---|
| Precio: | USD 850-1200/UNIT |
| Detalles de empaquetado: | paquete de madera contrachapada con película protectora |
| Tiempo de entrega: | 10-25 días |
| Condiciones de pago: | T/T, LC/C |
| Capacidad de la fuente: | 200 unidades por mes |
|
Información detallada |
|||
| Material: | Acero galvanizado, aleación de aluminio. | Grosor del panel: | 42MM |
|---|---|---|---|
| Ancho del panel: | 500 mm | Material del núcleo: | Espuma de Poliuretano 48kg/m3 |
| R-valor: | 13.73 | Velocidad de apertura: | 0.4m/s |
| Operación: | Eléctrico, remoto, manual | Conservación del calor: | 4,5 W/mh |
| Resistencia al viento: | Escala Beaufort 11, 28m/s | Aislamiento acústico: | 24 DB |
| Retardo en el fuego: | CLASE A | Vida útil: | 10 años |
| Dimensión máxima: | 12m x 8m | Tratamiento superficial: | Recubrimiento en polvo 30um |
| Solicitud: | Industrial, Almacén, Garaje, Comercial | ||
| Resaltar: | High Speed 0.4m/s Insulated Sectional Door,42mm PU Sandwich Panel Overhead Door,Energy Efficient R-Value 13.73 Sectional Door |
||
Descripción de producto
Energy Efficient High Speed Insulated Sectional Overhead Door
The SD6100 insulated sectional overhead door combines rapid 0.4m/s opening speed with industry-leading thermal performance. Designed for high-traffic industrial and commercial environments where both speed and energy efficiency are critical.
Key Features
- Industry-Leading R-Value 13.73: 42mm polyurethane foam sandwich panels deliver exceptional thermal insulation, reducing HVAC costs and maintaining stable indoor temperatures year-round.
- 0.4m/s High Speed Operation: Minimizes air exchange and heat loss during frequent open/close cycles, ideal for busy logistics centers and loading docks.
- 48kg/m3 High Density PU Core: Superior structural rigidity with excellent noise dampening at 24 dB sound insulation.
- Class A Fire Retardation: Meets stringent fire safety standards for industrial facilities.
- Beaufort 11 Wind Resistance: Engineered to withstand wind speeds up to 28m/s for exposed installations.
Technical Specifications
| Material | Galvanized Steel, Aluminum Alloy, Color Coating Plate |
| Panel Thickness | 42mm |
| Panel Width | 500mm |
| Core Density | 48kg/m3 Polyurethane Foam |
| R-Value | 13.73 |
| Opening Speed | 0.2-0.4m/s |
| Guide Rail Thickness | 2mm Galvanized Steel |
| Surface Treatment | Powder Coating 30um |
| Heat Preservation | 4.5W/m.h |
| Sealing | EPDM Rubber All-Round Sealing |
| Max Dimension | 12m x 8m |
| Power Supply | 380V 50Hz / 220V 50Hz |
| Service Life | 10 years / 100,000 cycles |
| Emergency Operation | Manual Hoist Chain |
Safety Systems
- Finger-protection (pinch-resistant) panel joint design
- Airbag safety edge for obstacle detection
- Door anti-fall device
- Wire rope anti-break protection
- Torsion spring balance system with spring brake device
Applications
Ideal for logistics warehouses, distribution centers, manufacturing plants, automotive workshops, and commercial garages where high-traffic access and thermal efficiency are priorities.
